斯坦福CS231n 课程学习笔记--线性分类器（Assignment1代码实现）

    import numpy as np
    def svm_loss_naive(W, X, y, reg):
    dW = np.zeros(W.shape)   # initialize the gradient as zero
    # compute the loss and the gradient
    num_classes = W.shape[1]
    num_train = X.shape[0]
    loss = 0.0
    #遍历样本集中的每一个样本
    for i in xrange(num_train):
        #计算得分，点乘
        scores = X[i].dot(W)
        #记录正确类别的得分
        correct_class_score = scores[y[i]]
        #遍历C个类别
        for j in xrange(num_classes):
            if j == y[i]:
                continue
            #计算折页损失，和梯度公式。公式推导在上篇博客中已经介绍过了
            margin = scores[j] - correct_class_score + 1   # note delta = 1
            if margin > 0:
                loss += margin
                dW[:, y[i]] += -X[i, :]     # compute the correct_class gradients
                dW[:, j] += X[i, :]         # compute the wrong_class gradients
    # Right now the loss is a sum over all training examples, but we want it
    # to be an average instead so we divide by num_train.
    loss /= num_train
    dW /= num_train
    # Add regularization to the loss.添加正则损失
    loss += 0.5 * reg * np.sum(W * W)
    dW += reg * W
    return loss, dW

    #使用向量运算计算loss和梯度
    def svm_loss_vectorized(W, X, y, reg):
    loss = 0.0
    dW = np.zeros(W.shape)   # initialize the gradient as zero
    #计算得分，是个矩阵N*C
    scores = X.dot(W)        # N by C
    num_train = X.shape[0]
    num_classes = W.shape[1]
    #记录所有样本的正确类别得分。该操作是获取1~N行中第y（数组n*1）个元素
    scores_correct = scores[np.arange(num_train), y]   # 1 by N
    scores_correct = np.reshape(scores_correct, (num_train, 1))  # N by 1
    #计算分数与正确分类的差
    margins = scores - scores_correct + 1.0     # N by C
    #正确分类处的误差为0
    margins[np.arange(num_train), y] = 0.0
    #小于0的位置也设置为0，即分类正确
    margins[margins <= 0] = 0.0
    loss += np.sum(margins) / num_train
    loss += 0.5 * reg * np.sum(W * W)
    # compute the gradient
    margins[margins > 0] = 1.0
    row_sum = np.sum(margins, axis=1)                  # 1 by N
    margins[np.arange(num_train), y] = -row_sum
    dW += np.dot(X.T, margins)/num_train + reg * W     # D by C

    return loss, dW

    import numpy as np
    #原理和svm一样。也分为两种计算方法。
    def softmax_loss_naive(W, X, y, reg):

    # Initialize the loss and gradient to zero.
    loss = 0.0
    dW = np.zeros_like(W)    # D by C
    dW_each = np.zeros_like(W)
    num_train, dim = X.shape
    num_class = W.shape[1]
    f = X.dot(W)    # N by C
    # Considering the Numeric Stability
    #考虑数值稳定性。减去f分值中最大的项。见上篇博客
    f_max = np.reshape(np.max(f, axis=1), (num_train, 1))   # N by 1
    #计算归一化概率
    prob = np.exp(f - f_max) / np.sum(np.exp(f - f_max), axis=1, keepdims=True) # N by C
    y_trueClass = np.zeros_like(prob)
    y_trueClass[np.arange(num_train), y] = 1.0
    for i in xrange(num_train):
        for j in xrange(num_class):
            loss += -(y_trueClass[i, j] * np.log(prob[i, j]))
            dW_each[:, j] = -(y_trueClass[i, j] - prob[i, j]) * X[i, :]
        dW += dW_each
    loss /= num_train
    loss += 0.5 * reg * np.sum(W * W)
    dW /= num_train
    dW += reg * W

    return loss, dW

    def softmax_loss_vectorized(W, X, y, reg):
    # Initialize the loss and gradient to zero.
    loss = 0.0
    dW = np.zeros_like(W)    # D by C
    num_train, dim = X.shape

    f = X.dot(W)    # N by C
    # Considering the Numeric Stability
    f_max = np.reshape(np.max(f, axis=1), (num_train, 1))   # N by 1
    prob = np.exp(f - f_max) / np.sum(np.exp(f - f_max), axis=1, keepdims=True)
    y_trueClass = np.zeros_like(prob)
    y_trueClass[range(num_train), y] = 1.0    # N by C
    loss += -np.sum(y_trueClass * np.log(prob)) / num_train + 0.5 * reg * np.sum(W * W)
    dW += -np.dot(X.T, y_trueClass - prob) / num_train + reg * W

    return loss, dW

    from linear_svm import *
    from softmax import *

    class LinearClassifier(object):

    def __init__(self):
        self.W = None

    def train(self, X, y, learning_rate=1e-3, reg=1e-5, num_iters=100, batch_size=200, verbose=True):
        num_train, dim = X.shape
        # assume y takes values 0...K-1 where K is number of classes
        num_classes = np.max(y) + 1
        if self.W is None:
            # lazily initialize W
            self.W = 0.001 * np.random.randn(dim, num_classes)   # D by C

        # Run stochastic gradient descent(Mini-Batch) to optimize W
        loss_history = []
        for it in xrange(num_iters):
            X_batch = None
            y_batch = None
            # Sampling with replacement is faster than sampling without replacement.
            sample_index = np.random.choice(num_train, batch_size, replace=False)
            X_batch = X[sample_index, :]   # batch_size by D
            y_batch = y[sample_index]      # 1 by batch_size
            # evaluate loss and gradient
            loss, grad = self.loss(X_batch, y_batch, reg)
            loss_history.append(loss)

            # perform parameter update
            self.W += -learning_rate * grad
            if verbose and it % 100 == 0:
                print 'Iteration %d / %d: loss %f' % (it, num_iters, loss)

        return loss_history

    def predict(self, X):
        y_pred = np.zeros(X.shape[1])    # 1 by N
        y_pred = np.argmax(np.dot(self.W.T, X.T), axis=0)
        return y_pred

    def loss(self, X_batch, y_batch, reg):
        pass

    class LinearSVM(LinearClassifier):
      """ A subclass that uses the Multiclass SVM loss function """

      def loss(self, X_batch, y_batch, reg):
    return svm_loss_vectorized(self.W, X_batch, y_batch, reg)

    class Softmax(LinearClassifier):
      """ A subclass that uses the Softmax + Cross-entropy loss function """

      def loss(self, X_batch, y_batch, reg):
    return softmax_loss_vectorized(self.W, X_batch, y_batch, reg)

    # softmax.ipynb

    from cs231n.classifiers import Softmax
    results = {}
    best_val = -1
    best_softmax = None
    learning_rates = [5e-6, 1e-7, 5e-7]
    regularization_strengths = [1e4, 5e4, 1e5]
    params = [(x,y) for x in learning_rates for y in regularization_strengths ]
    for lrate, regular in params:
    softmax = Softmax()
    loss_hist = softmax.train(X_train, y_train, learning_rate=lrate, reg=regular,
                             num_iters=700, verbose=True)
    y_train_pred = softmax.predict(X_train)
    accuracy_train = np.mean( y_train == y_train_pred)
    y_val_pred = softmax.predict(X_val)
    accuracy_val = np.mean(y_val == y_val_pred)
    results[(lrate, regular)] = (accuracy_train, accuracy_val)
    if(best_val < accuracy_val):
        best_val = accuracy_val
        best_softmax = softmax

    # Print out results.
    for lr, reg in sorted(results):
    train_accuracy, val_accuracy = results[(lr, reg)]
    print 'lr %e reg %e train accuracy: %f val accuracy: %f' % (
                lr, reg, train_accuracy, val_accuracy)

    print 'best validation accuracy achieved during cross-validation: %f' % best_val


    # svm.ipynb

    from cs231n.classifiers import LinearSVM
    learning_rates = [1e-7, 5e-5]
    regularization_strengths = [5e4, 1e5]

    results = {}
    best_val = -1   # The highest validation accuracy that we have seen so far.
    best_svm = None # The LinearSVM object that achieved the highest validation rate.

    iters= 1000
    for lr in learning_rates:
    for rs in regularization_strengths:
        svm = LinearSVM()
        svm.train(X_train, y_train, learning_rate=lr, reg=rs, num_iters=iters)
        y_train_pred = svm.predict(X_train)
        acc_train = np.mean(y_train == y_train_pred)
        y_val_pred = svm.predict(X_val)
        acc_val = np.mean(y_val == y_val_pred)
        results[(lr, rs)] = (acc_train, acc_val)
        if best_val < acc_val:
            best_val = acc_val
            best_svm = svm

    # Print out results.
    for lr, reg in sorted(results):
    train_accuracy, val_accuracy = results[(lr, reg)]
    print 'lr %e reg %e train accuracy: %f val accuracy: %f' % (
                lr, reg, train_accuracy, val_accuracy)

    print 'best validation accuracy achieved during cross-validation: %f' % best_val
