【图像识别】CIFAR-10（CNN）

>       1. import tensorflow as tf

>
>       2. import numpy as np
>
>       3. import time
>
>       4. import math
>
>       5. # 官方提供的两个文件，用于对数据集的输入等操作
>
>       6. import cifar10
>
>       7. import cifar10_input
>
>       8.
>
>       9. max_steps = 3000 # 训练次数
>
>       10. batch_size = 128 # 批处理参数
>
>       11.
>
>       12. # ---1.加载数据 ---
>
>       13.
>
>       14. # 下载cifar10数据集的默认路径，需要把cifar10.py/line 53/对应代码改一下
>
>       15. data_dir = 'D:/Python_code/Data/cifar-10-python/cifar-10-batches-bin'
>
>       16.
>
>       17. # 权值初始化函数（shape，标准差，L2正则化比例系数）
>
>       18. def variable_with_weight_losses(shape, stddev, wl):
>
>       19.   # 使用tf.truncated_normal截断的正态分布来初始化
>
>       20.   var = tf.Variable(tf.truncated_normal(shape, stddev=stddev))
>
>       21.   if wl is not None:
>
>       22.     # 做一个L2的正则化处理，用wl控制L2的大小比例
>
>       23.     weight_loss = tf.multiply(tf.nn.l2_loss(var), wl, name='weight_loss')
>
>       24.     # 将weight_loss统一存放起来
>
>       25.     tf.add_to_collection("losses", weight_loss)
>
>       26.   return var
>
>       27.
>
>       28. # 调用cifar10.py中的一个函数，下载数据集，并解压
>
>       29. cifar10.maybe_download_and_extract()
>
>       30.
>
>       31. # 生成训练数据，使用distorted_inputs函数，做数据增强处理
>
>       32. images_train, labels_train = cifar10_input.distorted_inputs(data_dir=data_dir, batch_size=batch_size)
>
>       33. # 生成测试数据，不必做数据增强
>
>       34. images_test, labels_test = cifar10_input.inputs(eval_data=True, data_dir=data_dir, batch_size=batch_size)
>
>       35.
>
>       36. # 占位符
>
>       37. image_holder = tf.placeholder(tf.float32, [batch_size, 24, 24, 3])
>
>       38. label_holder = tf.placeholder(tf.int32, [batch_size])
>
>       39.
>
>       40.
>
>       41. # ---2. 构建模型 ---
>
>       42.
>
>       43. # 第一层卷积层，64个卷积核，大小为5*5，3通道（RGB三种颜色通道）
>
>       44.   # 1).定义权重
>
>       45. weight1 = variable_with_weight_losses(shape=[5,5,3,64], stddev=0.05, wl=0.0)
>
>       46.   # 2).卷积操作
>
>       47. kernel1 = tf.nn.conv2d(image_holder, filter=weight1, strides=[1, 1, 1, 1], padding='SAME')
>
>       48.   # 3).定义偏差
>
>       49. bias1 = tf.Variable(tf.constant(0.0, shape=[64]))
>
>       50.   # 4).relu激活函数
>
>       51. conv1 = tf.nn.relu(tf.nn.bias_add(kernel1, bias1))
>
>       52.   # 5).最大池化
>
>       53. pool1 = tf.nn.max_pool(conv1, ksize=[1, 3, 3, 1], strides=[1, 2, 2, 1], padding='SAME')
>
>       54.   # 6.lrn: 局部响应归一化，可防止过拟合，原理是生物学上的‘侧抑制’，（通俗来讲就是增强强的地方，削弱弱的地方）
>
>       55.   # pool1表示输入数据，4表示使用前后几层进行归一化操作，bias表示偏移量，alpha和beta表示系数
>
>       56. norm1 = tf.nn.lrn(pool1, 4, bias=1.0, alpha=0.001/9.0, beta=0.75)
>
>       57.
>
>       58. # 第二层卷积层
>
>       59. weight2 = variable_with_weight_losses(shape=[5,5,64,64], stddev=5e-2, wl=0.0)
>
>       60. kernel2 = tf.nn.conv2d(norm1, filter=weight2, strides=[1, 1, 1, 1], padding='SAME')
>
>       61. bias2 = tf.Variable(tf.constant(0.1, shape=[64]))
>
>       62. conv2 = tf.nn.relu(tf.nn.bias_add(kernel2, bias2))
>
>       63. norm2 = tf.nn.lrn(conv2, 4, bias=1.0, alpha=0.001/9.0, beta=0.75)
>
>       64. pool2 = tf.nn.max_pool(norm2, ksize=[1, 3, 3, 1], strides=[1, 2, 2, 1], padding='SAME')
>
>       65.
>
>       66. # 第三层全连接层
>
>       67. # 将第二层卷积层输出结果变成一维向量
>
>       68. reshape = tf.reshape(pool2, [batch_size, -1])
>
>       69. dim = reshape.get_shape()[1].value
>
>       70. # 初始化权值，隐含节点384个，正态分布标准差为0.04，偏差bias为0.1
>
>       71. weight3 = variable_with_weight_losses(shape=[dim,384], stddev=0.04, wl=0.004)
>
>       72. bias3 = tf.Variable(tf.constant(0.1, shape=[384]))
>
>       73. local3 = tf.nn.relu(tf.matmul(reshape, weight3) + bias3)
>
>       74.
>
>       75. # 第四层全连接层
>
>       76. weight4 = variable_with_weight_losses(shape=[384,192], stddev=0.04, wl=0.004)
>
>       77. bias4 = tf.Variable(tf.constant(0.1, shape=[192]))
>
>       78. local4 = tf.nn.relu(tf.matmul(local3, weight4) + bias4)
>
>       79.
>
>       80. # 第五层输出层
>
>       81. weight5 = variable_with_weight_losses(shape=[192,10], stddev=1/192.0, wl=0.0)
>
>       82. bias5 = tf.Variable(tf.constant(0.0, shape=[10]))
>
>       83. logits = tf.add(tf.matmul(local4, weight5), bias5)
>
>       84.
>
>       85. # 定义损失函数
>
>       86. def loss(logits, labels):
>
>       87.   labels = tf.cast(labels, tf.int64)
>
>       88.   # 交叉熵损失函数
>
>       89.   cross_entropy = tf.reduce_mean(tf.nn.sparse_softmax_cross_entropy_with_logits(
>
>       90.     logits=logits, labels=labels
>
>       91.   ))
>
>       92.   tf.add_to_collection('losses', cross_entropy)
>
>       93.   return tf.add_n(tf.get_collection('losses'), name='total_loss')
>
>       94.
>
>       95. loss = loss(logits=logits,labels=label_holder)
>
>       96. train_op = tf.train.AdamOptimizer(0.001).minimize(loss)
>
>       97. top_k_op = tf.nn.in_top_k(logits, label_holder, 1)
>
>       98.
>
>       99. # ---3. 训练模型---
>
>       100. sess = tf.InteractiveSession()
>
>       101. tf.global_variables_initializer().run()
>
>       102. # 引入多线程
>
>       103. tf.train.start_queue_runners()
>
>       104.
>
>       105. for step in range(max_steps):
>
>       106.   start_time = time.time()
>
>       107.   image_batch, label_batch = sess.run([images_train, labels_train])
>
>       108.   _, loss_value = sess.run([train_op, loss], feed_dict={image_holder: image_batch, label_holder: label_batch})
>
>       109.   duration = time.time() - start_time
>
>       110.   if step % 10 == 0:
>
>       111.     examples_per_sec = batch_size / duration
>
>       112.     sec_per_batch = float(duration)
>
>       113.     str = 'step %d, loss = %.2f (%.1f examples/sec; %.3f sec/batch)'
>
>       114.     #print(step, loss_value)
>
>       115.     print(str % (step, loss_value, examples_per_sec, sec_per_batch))
>
>       116.
>
>       117. num_examples = 10000
>
>       118. num_iter = int(math.ceil(num_examples / batch_size))
>
>       119. true_count = 0
>
>       120. total_sample_count = num_iter * batch_size
>
>       121. step = 0
>
>       122. while step < num_iter:
>
>       123.   image_batch, label_batch = sess.run([images_test, labels_test])
>
>       124.   predictions = sess.run([top_k_op], feed_dict={image_holder: image_batch, label_holder: label_batch})
>
>       125.   true_count += np.sum(predictions)
>
>       126.   step += 1
>
>       127.
>
>       128. precision = true_count / total_sample_count
>
>       129. print('precision = %.3f' % precision)
>
>
>
