医学图像分割实战——使用U-Net实现肾脏CT分割

    import argparse
    import logging
    import os
    import sys

    import numpy as np
    import torch
    import torch.nn as nn
    from torch import optim
    from tqdm import tqdm

    from eval import eval_net
    from unet import UNet

    from visdom import Visdom
    from utils.dataset import BasicDataset
    from torch.utils.data import DataLoader, random_split

    dir_img = 'D:\Dataset\CT-KiTS19\KiTS19\kits19-master\png_datasize\ train_choose\slice_png'
    dir_mask = 'D:\Dataset\CT-KiTS19\KiTS19\kits19-master\png_datasize\ train_choose\mask_png'
    dir_checkpoint = 'checkpoints/'


    def train_net(net,
              device,
              epochs=5,
              batch_size=1,
              lr=0.1,
              val_percent=0.2,
              save_cp=True,
              img_scale=1):

    dataset = BasicDataset(dir_img, dir_mask, img_scale)
    n_val = int(len(dataset) * val_percent)
    n_train = len(dataset) - n_val
    train, val = random_split(dataset, [n_train, n_val])
    train_loader = DataLoader(train, batch_size=batch_size, shuffle=True, num_workers=4, pin_memory=True)
    val_loader = DataLoader(val, batch_size=batch_size, shuffle=False, num_workers=4, pin_memory=True, drop_last=True)

    #writer = SummaryWriter(comment=f'LR_{lr}_BS_{batch_size}_SCALE_{img_scale}')
    viz=Visdom()
    viz.line([0.], [0.], win='train_loss', opts=dict(title='train_loss'))
    viz.line([0.], [0.], win='learning_rate', opts=dict(title='learning_rate'))
    viz.line([0.], [0.], win='Dice/test', opts=dict(title='Dice/test'))

    global_step = 0

    logging.info(f'''Starting training:
        Epochs:          {epochs}
        Batch size:      {batch_size}
        Learning rate:   {lr}
        Training size:   {n_train}
        Validation size: {n_val}
        Checkpoints:     {save_cp}
        Device:          {device.type}
        Images scaling:  {img_scale}
    ''')

    optimizer = optim.RMSprop(net.parameters(), lr=lr, weight_decay=1e-8, momentum=0.9)
    scheduler = optim.lr_scheduler.ReduceLROnPlateau(optimizer, 'min' if net.n_classes > 1 else 'max', patience=2)
    if net.n_classes > 1:
        criterion = nn.CrossEntropyLoss()
    else:
        criterion = nn.BCEWithLogitsLoss()

    for epoch in range(epochs):
        net.train()

        epoch_loss = 0
        with tqdm(total=n_train, desc=f'Epoch {epoch + 1}/{epochs}', unit='img') as pbar:
            for batch in train_loader:
                imgs = batch['image']
                true_masks = batch['mask']
                assert imgs.shape[1] == net.n_channels, \
                    f'Network has been defined with {net.n_channels} input channels, ' \
                    f'but loaded images have {imgs.shape[1]} channels. Please check that ' \
                    'the images are loaded correctly.'

                imgs = imgs.to(device=device, dtype=torch.float32)
                mask_type = torch.float32 if net.n_classes == 1 else torch.long
                true_masks = true_masks.to(device=device, dtype=mask_type)

                masks_pred = net(imgs)

                #print('mask_pred',masks_pred.shape)
                #print('masks_pred',masks_pred.shape)
                #print('true_masks', true_masks.shape)
                viz.image(imgs, win='imgs/train')
                viz.image(true_masks, win='masks/true/train')
                viz.image(masks_pred, win='masks/pred/train')
                loss = criterion(masks_pred, true_masks)
                epoch_loss += loss.item()
                #writer.add_scalar('Loss/train', loss.item(), global_step)
                viz.line([loss.item()],[global_step],win='train_loss',update='append')
                pbar.set_postfix(**{'loss (batch)': loss.item()})

                optimizer.zero_grad()
                loss.backward()
                #nn.utils.clip_grad_value_(net.parameters(), 0.1)
                optimizer.step()

                pbar.update(imgs.shape[0])
                global_step += 1

                if global_step % (n_train // (10 * batch_size)) == 0:
                    # for tag, value in net.named_parameters():
                    #     tag = tag.replace('.', '/')
                    #     writer.add_histogram('weights/' + tag, value.data.cpu().numpy(), global_step)
                    #     writer.add_histogram('grads/' + tag, value.grad.data.cpu().numpy(), global_step)
                    val_score = eval_net(net, val_loader, device)
                    scheduler.step(val_score)
                    #writer.add_scalar('learning_rate', optimizer.param_groups[0]['lr'], global_step)
                    viz.line([optimizer.param_groups[0]['lr']], [global_step], win='learning_rate', update='append')

                    if net.n_classes > 1:
                        logging.info('Validation cross entropy: {}'.format(val_score))
                        #writer.add_scalar('Loss/test', val_score, global_step)
                    else:
                        logging.info('Validation Dice Coeff: {}'.format(val_score))
                        #writer.add_scalar('Dice/test', val_score, global_step)
                        viz.line([val_score], [global_step], win='Dice/test', update='append')

                    viz.image(imgs, win='images')
                    if net.n_classes == 1:
                        print('true_mask',true_masks.shape,true_masks.type)
                        viz.image( true_masks, win='masks/true')
                        print('pred',(torch.sigmoid(masks_pred) > 0.5).squeeze(0).shape)
                        viz.images((torch.sigmoid(masks_pred) > 0.5),win='masks/pred')

        if save_cp:
            try:
                os.mkdir(dir_checkpoint)
                logging.info('Created checkpoint directory')
            except OSError:
                pass
            torch.save(net.state_dict(),
                       dir_checkpoint + f'CP_epoch{epoch + 1}.pth')
            logging.info(f'Checkpoint {epoch + 1} saved !')

    #writer.close()

    def eval_net(net, loader, device):
    """Evaluation without the densecrf with the dice coefficient"""
    net.eval()
    mask_type = torch.float32 #if net.n_classes == 1 else torch.long
    n_val = len(loader)  # the number of batch
    tot = 0

    with tqdm(total=n_val, desc='Validation round', unit='batch', leave=False) as pbar:
        for batch in loader:
            imgs, true_masks = batch['image'], batch['mask']
            imgs = imgs.to(device=device, dtype=torch.float32)
            true_masks = true_masks.to(device=device, dtype=mask_type)

            with torch.no_grad():
                mask_pred = net(imgs)#['out']

            # if net.n_classes > 1:
            #     tot += F.cross_entropy(mask_pred, true_masks).item()
            # else:
            pred = torch.sigmoid(mask_pred)
            pred = (pred > 0.5).float()
            tot += dice_coeff(pred, true_masks).item()
            pbar.update()

    net.train()
    return tot / n_val


    def get_args():
    parser = argparse.ArgumentParser(description='Train the UNet on images and target masks',
                                     formatter_class=argparse.ArgumentDefaultsHelpFormatter)
    parser.add_argument('-e', '--epochs', metavar='E', type=int, default=5,
                        help='Number of epochs', dest='epochs')
    parser.add_argument('-b', '--batch-size', metavar='B', type=int, nargs='?', default=1,
                        help='Batch size', dest='batchsize')
    parser.add_argument('-l', '--learning-rate', metavar='LR', type=float, nargs='?', default=0.1,
                        help='Learning rate', dest='lr')
    parser.add_argument('-f', '--load', dest='load', type=str, default=False,
                        help='Load model from a .pth file')
    parser.add_argument('-s', '--scale', dest='scale', type=float, default=1,
                        help='Downscaling factor of the images')
    parser.add_argument('-v', '--validation', dest='val', type=float, default=20.0,
                        help='Percent of the data that is used as validation (0-100)')

    return parser.parse_args()


    if __name__ == '__main__':
    logging.basicConfig(level=logging.INFO, format='%(levelname)s: %(message)s')
    args = get_args()
    device = torch.device('cuda' if torch.cuda.is_available() else 'cpu')
    logging.info(f'Using device {device}')

    # Change here to adapt to your data
    # n_channels=3 for RGB images
    # n_classes is the number of probabilities you want to get per pixel
    #   - For 1 class and background, use n_classes=1
    #   - For 2 classes, use n_classes=1
    #   - For N > 2 classes, use n_classes=N
    net = UNet(n_channels=1, n_classes=1, bilinear=True)
    logging.info(f'Network:\n'
                 f'\t{net.n_channels} input channels\n'
                 f'\t{net.n_classes} output channels (classes)\n'
                 f'\t{"Bilinear" if net.bilinear else "Transposed conv"} upscaling')

    if args.load:
        net.load_state_dict(
            torch.load(args.load, map_location=device)
        )
        logging.info(f'Model loaded from {args.load}')

    net.to(device=device)
    # faster convolutions, but more memory
    # cudnn.benchmark = True

    try:
        train_net(net=net,
                  epochs=args.epochs,
                  batch_size=args.batchsize,
                  lr=args.lr,
                  device=device,
                  img_scale=args.scale,
                  val_percent=args.val / 100)
    except KeyboardInterrupt:
        torch.save(net.state_dict(), 'INTERRUPTED.pth')
        logging.info('Saved interrupt')
        try:
            sys.exit(0)
        except SystemExit:
            os._exit(0)
