【强化学习】Soft Actor-Critic (SAC) 算法

 * 最小化以下损失函数： ![J_Q = \mathbb{E} \left\[ \left\( Q_{\theta_i}\(s, a\) - y \right\)^2 \right\] \quad \(i = 1, 2\)](https://ad.itadn.com/c/weblog/00-blog-img/images/2025-02-27/uAjydWl0YGU84t9pCxM1LaeIFXvz.png)

 * 最小化值函数损失：![J_V = \mathbb{E} \left\[ \left\( V_\psi\(s\) - y_V \right\)^2 \right\]](https://ad.itadn.com/c/weblog/00-blog-img/images/2025-02-27/rQagHpXBvNMc1Z6ESYyxDzPUVqmo.png)

 * 策略网络的目标是最大化奖励和熵，最小化以下损失：

 """《SAC, Soft Actor-Critic算法》


     时间：2024.12

     作者：不去幼儿园

 """

 import torch  # 引入 PyTorch 库，用于构建和训练深度学习模型

 import torch.nn as nn  # PyTorch 的神经网络模块

 import torch.optim as optim  # PyTorch 的优化模块，用于更新模型参数

 import numpy as np  # NumPy 库，用于高效的数值计算

 import gym  # OpenAI Gym 库，用于创建和交互强化学习环境

 import random  # Python 的随机模块，用于随机抽样

 from collections import deque  # Python 的双端队列模块，用于构建经验回放缓冲区



 # 超参数设置

 GAMMA = 0.99  # 折扣因子，用于计算未来奖励

 TAU = 0.005  # 软更新目标网络的参数

 ALPHA = 0.2  # 熵正则化系数，鼓励探索

 LR = 0.001  # 学习率，用于优化器

 BATCH_SIZE = 256  # 每次训练的样本数量

 MEMORY_CAPACITY = 100000  # 经验回放缓冲区的最大容量

 # 策略网络（用于生成随机的策略动作）


 class PolicyNetwork(nn.Module):

     def __init__(self, state_dim, action_dim, max_action):

     super(PolicyNetwork, self).__init__()

     self.fc1 = nn.Linear(state_dim, 256)  # 第一层全连接层，输入状态维度

     self.fc2 = nn.Linear(256, 256)  # 第二层全连接层

     self.mean = nn.Linear(256, action_dim)  # 输出动作均值

     self.log_std = nn.Linear(256, action_dim)  # 输出动作的对数标准差

     self.max_action = max_action  # 动作的最大值，用于缩放



     def forward(self, state):

     x = torch.relu(self.fc1(state))  # 激活第一层

     x = torch.relu(self.fc2(x))  # 激活第二层

     mean = self.mean(x)  # 计算动作均值

     log_std = self.log_std(x).clamp(-20, 2)  # 将对数标准差限制在合理范围内

     std = torch.exp(log_std)  # 通过对数标准差计算标准差

     return mean, std  # 返回均值和标准差



     def sample(self, state):

     mean, std = self.forward(state)  # 获取动作分布的均值和标准差

     normal = torch.distributions.Normal(mean, std)  # 正态分布

     x_t = normal.rsample()  # 使用重参数化技巧采样

     y_t = torch.tanh(x_t)  # 使用 Tanh 将动作限制在 [-1, 1]

     action = y_t * self.max_action  # 缩放动作到最大值范围

     log_prob = normal.log_prob(x_t)  # 计算动作的对数概率

     log_prob -= torch.log(1 - y_t.pow(2) + 1e-6)  # Tanh 的修正项

     log_prob = log_prob.sum(dim=-1, keepdim=True)  # 对每个维度求和

     return action, log_prob  # 返回动作和对数概率

 # Q 网络（价值函数，用于评估状态-动作对的价值）


 class QNetwork(nn.Module):

     def __init__(self, state_dim, action_dim):

     super(QNetwork, self).__init__()

     self.fc1 = nn.Linear(state_dim + action_dim, 256)  # 输入包括状态和动作

     self.fc2 = nn.Linear(256, 256)  # 第二层全连接层

     self.fc3 = nn.Linear(256, 1)  # 输出单一 Q 值



     def forward(self, state, action):

     x = torch.cat([state, action], dim=-1)  # 将状态和动作连接起来作为输入

     x = torch.relu(self.fc1(x))  # 激活第一层

     x = torch.relu(self.fc2(x))  # 激活第二层

     x = self.fc3(x)  # 输出 Q 值

     return x  # 返回 Q 值

 # 经验回放缓冲区


 class ReplayBuffer:

     def __init__(self, capacity):

     self.buffer = deque(maxlen=capacity)  # 初始化一个具有固定最大容量的双端队列



     def push(self, state, action, reward, next_state, done):  # 存储经验

     self.buffer.append((state, action, reward, next_state, done))



     def sample(self, batch_size):  # 随机采样

     batch = random.sample(self.buffer, batch_size)  # 随机选取 batch_size 个经验

     states, actions, rewards, next_states, dones = zip(*batch)  # 解压

     return (np.array(states), np.array(actions), np.array(rewards),

             np.array(next_states), np.array(dones))



     def __len__(self):  # 返回缓冲区当前大小

     return len(self.buffer)



 # SAC 算法智能体

 class SACAgent:

     def __init__(self, state_dim, action_dim, max_action):

     self.device = torch.device("cuda" if torch.cuda.is_available() else "cpu")  # 检查是否有 GPU



     # 初始化网络

     self.actor = PolicyNetwork(state_dim, action_dim, max_action).to(self.device)  # 策略网络

     self.q1 = QNetwork(state_dim, action_dim).to(self.device)  # 第一个 Q 网络

     self.q2 = QNetwork(state_dim, action_dim).to(self.device)  # 第二个 Q 网络



     # 初始化优化器

     self.actor_optimizer = optim.Adam(self.actor.parameters(), lr=LR)  # 策略网络优化器

     self.q1_optimizer = optim.Adam(self.q1.parameters(), lr=LR)  # Q1 优化器

     self.q2_optimizer = optim.Adam(self.q2.parameters(), lr=LR)  # Q2 优化器



     # 初始化经验回放缓冲区

     self.replay_buffer = ReplayBuffer(MEMORY_CAPACITY)

     self.max_action = max_action  # 最大动作值



     def select_action(self, state):  # 根据策略选择动作

     state = torch.FloatTensor(state).to(self.device).unsqueeze(0)  # 转换状态为张量

     action, _ = self.actor.sample(state)  # 从策略中采样动作

     return action.cpu().detach().numpy()[0]  # 转换为 NumPy 格式返回



     def train(self):  # 训练智能体

     if len(self.replay_buffer) < BATCH_SIZE:  # 如果经验回放缓冲区不足，跳过训练

         return



     # 从回放缓冲区采样

     states, actions, rewards, next_states, dones = self.replay_buffer.sample(BATCH_SIZE)

     states = torch.FloatTensor(states).to(self.device)

     actions = torch.FloatTensor(actions).to(self.device)

     rewards = torch.FloatTensor(rewards).unsqueeze(1).to(self.device)

     next_states = torch.FloatTensor(next_states).to(self.device)

     dones = torch.FloatTensor(dones).unsqueeze(1).to(self.device)



     # 更新 Q 网络

     with torch.no_grad():

         next_actions, log_probs = self.actor.sample(next_states)  # 计算下一步的动作及其概率

         target_q1 = self.q1(next_states, next_actions)  # Q1 值

         target_q2 = self.q2(next_states, next_actions)  # Q2 值

         target_q = torch.min(target_q1, target_q2) - ALPHA * log_probs  # 使用最小值更新

         q_target = rewards + GAMMA * (1 - dones) * target_q  # 计算目标 Q 值



     q1_loss = ((self.q1(states, actions) - q_target) ** 2).mean()  # Q1 损失

     q2_loss = ((self.q2(states, actions) - q_target) ** 2).mean()  # Q2 损失



     self.q1_optimizer.zero_grad()  # 清空梯度

     q1_loss.backward()  # 反向传播

     self.q1_optimizer.step()  # 更新 Q1



     self.q2_optimizer.zero_grad()

     q2_loss.backward()

     self.q2_optimizer.step()



     # 更新策略网络

     new_actions, log_probs = self.actor.sample(states)

     q1_new = self.q1(states, new_actions)

     q2_new = self.q2(states, new_actions)

     q_new = torch.min(q1_new, q2_new)



     actor_loss = (ALPHA * log_probs - q_new).mean()  # 策略损失



     self.actor_optimizer.zero_grad()

     actor_loss.backward()

     self.actor_optimizer.step()



     def update_replay_buffer(self, state, action, reward, next_state, done):

     self.replay_buffer.push(state, action, reward, next_state, done)

 # 训练循环


 env = gym.make("Pendulum-v1")  # 创建环境

 state_dim = env.observation_space.shape[0]  # 状态空间维度

 action_dim = env.action_space.shape[0]  # 动作空间维度

 max_action = float(env.action_space.high[0])  # 最大动作值



 agent = SACAgent(state_dim, action_dim, max_action)  # 初始化智能体



 num_episodes = 500  # 训练的总回合数

 for episode in range(num_episodes):

     state = env.reset()  # 重置环境

     episode_reward = 0  # 初始化总奖励

     done = False



     while not done:

     action = agent.select_action(state)  # 根据策略选择动作

     next_state, reward, done, _ = env.step(action)  # 执行动作

     agent.update_replay_buffer(state, action, reward, next_state, done)  # 更新经验

     agent.train()  # 训练智能体

     state = next_state  # 更新状态

     episode_reward += reward  # 累积奖励



     print(f"Episode {episode}, Reward: {episode_reward}")  # 打印回合奖励

 ​# 环境配置


 Python                  3.11.5

 torch                   2.1.0

 torchvision             0.16.0

 gym                     0.26.2
