2024mathorcup妈妈杯数学建模B题思路模型

 %% 预处理


 % 初始化closeList

 closeList = start_node;

 closeList_path = {start_node,start_node};

 closeList_cost = 0;

 child_nodes = child_nodes_cal(start_node,  m, n, obs, closeList); %子节点搜索函数



 % 初始化openList

 openList = child_nodes;

 for i = 1:size(openList,1)

     openList_path{i,1} = openList(i,:);

     openList_path{i,2} = [start_node;openList(i,:)];%从初始点到第i个子节点

 end



 for i = 1:size(openList, 1)

     g = norm(start_node - openList(i,1:2));%norm求范数，返回最大奇异值；abs求绝对值

     h = abs(target_node(1) - openList(i,1)) + abs(target_node(2) - openList(i,2));

     %终点横坐标距离加纵坐标距离

     f = g + h;

     openList_cost(i,:) = [g, h, f];

 end



 %% 开始搜索

 % 从openList开始搜索移动代价最小的节点

 [~, min_idx] = min(openList_cost(:,3));%输出openlist_cost表中最小值的位置

 parent_node = openList(min_idx,:);%父节点为代价最小节点





 %% 进入循环

 flag = 1;

 while flag



     % 找出父节点的忽略closeList的子节点

     child_nodes = child_nodes_cal(parent_node,  m, n, obs, closeList);



     % 判断这些子节点是否在openList中，若在，则比较更新；没在则追加到openList中

     for i = 1:size(child_nodes,1)

     child_node = child_nodes(i,:);

     [in_flag,openList_idx] = ismember(child_node, openList, 'rows');%ismember函数表示子节点在open表中则返回1，判断flag,输出此子节点在openlist表中的位置

     g = openList_cost(min_idx, 1) + norm(parent_node - child_node);%按照新父节点计算此子节点的g,h值

     h = abs(child_node(1) - target_node(1)) + abs(child_node(2) - target_node(2));

     f = g+h;



     if in_flag   % 若在，比较更新g和f

         if g < openList_cost(openList_idx,1)

             openList_cost(openList_idx, 1) = g;%将openlist_cost表中第id个位置的第一个数更新为以新父节点计算的g值

             openList_cost(openList_idx, 3) = f;

             openList_path{openList_idx,2} = [openList_path{min_idx,2}; child_node];

         end

     else         % 若不在，追加到openList

         openList(end+1,:) = child_node;

         openList_cost(end+1, :) = [g, h, f];

         openList_path{end+1, 1} = child_node;

         openList_path{end, 2} = [openList_path{min_idx,2}; child_node];

     end

     end





     % 从openList移除移动代价最小的节点到 closeList

     closeList(end+1,: ) =  openList(min_idx,:);

     closeList_cost(end+1,1) =   openList_cost(min_idx,3);

     closeList_path(end+1,:) = openList_path(min_idx,:);

     openList(min_idx,:) = [];%openlist表中已跳出的最小值位置设为空

     openList_cost(min_idx,:) = [];

     openList_path(min_idx,:) = [];



     % 重新搜索：从openList搜索移动代价最小的节点（重复步骤）

     [~, min_idx] = min(openList_cost(:,3));

     parent_node = openList(min_idx,:);



     % 判断是否搜索到终点

     if parent_node == target_node

     closeList(end+1,: ) =  openList(min_idx,:);

     closeList_cost(end+1,1) =   openList_cost(min_idx,1);

     closeList_path(end+1,:) = openList_path(min_idx,:);

     flag = 0;

     end

 end
