如何训练自己的数据集之——DIOR遥感小目标目标检测数据集

 DIOR_dataset/


 ├── train/

 │   ├── images/

 │   │   ├── image_0001.jpg

 │   │   ├── image_0002.jpg

 │   │   └── ...

 │   ├── labels_yolo/

 │   │   ├── image_0001.txt

 │   │   ├── image_0002.txt

 │   │   └── ...

 │   ├── labels_voc/

 │   │   ├── image_0001.xml

 │   │   ├── image_0002.xml

 │   │   └── ...

 ├── valid/

 │   ├── images/

 │   │   ├── image_0001.jpg

 │   │   ├── image_0002.jpg

 │   │   └── ...

 │   ├── labels_yolo/

 │   │   ├── image_0001.txt

 │   │   ├── image_0002.txt

 │   │   └── ...

 │   ├── labels_voc/

 │   │   ├── image_0001.xml

 │   │   ├── image_0002.xml

 │   │   └── ...

 └── data.yaml  # 数据集配置文件




    AI写代码

 # data.yaml 文件


 train: ../DIOR_dataset/train/images/

 val: ../DIOR_dataset/valid/images/

 test: null  # 如果有单独的测试集路径，则填写



 nc: 20  # number of classes

 names: ['harbor', 'ship', 'storagetank', 'chimney', 'dam', 'trainstation', 'basketballcourt', 'airport', 'expressway-service-area', 'airplane', 'baseballfield', 'expressway-toll-station', 'vehicle', 'golffield', 'bridge', 'groundtrackfield', 'overpass', 'windmill', 'tenniscourt', 'stadium']




    AI写代码

 git clone https://github.com/ultralytics/ultralytics.git  # 克隆YOLOv8仓库


 cd ultralytics

 pip install -r requirements.txt  # 安装依赖项




    AI写代码

 import xml.etree.ElementTree as ET


 import os



 def convert_voc_to_yolo(xml_file_path, txt_file_path, img_width, img_height):

     tree = ET.parse(xml_file_path)

     root = tree.getroot()



     with open(txt_file_path, 'w') as txt_file:

     for obj in root.iter('object'):

         difficult = obj.find('difficult').text

         cls = obj.find('name').text

         if int(difficult) == 1 or int(difficult) == -1:

             continue

         cls_id = names.index(cls)

         xmlbox = obj.find('bndbox')

         b = (int(float(xmlbox.find('xmin').text)),

              int(float(xmlbox.find('xmax').text)),

              int(float(xmlbox.find('ymin').text)),

              int(float(xmlbox.find('ymax').text)))



         # 将坐标转换为YOLO格式

         x_center = (b[0] + b[1]) / 2.0

         y_center = (b[2] + b[3]) / 2.0

         width = b[1] - b[0]

         height = b[3] - b[2]



         x_center /= img_width

         y_center /= img_height

         width /= img_width

         height /= img_height



         txt_file.write(f"{cls_id} {x_center:.6f} {y_center:.6f} {width:.6f} {height:.6f}\n")



 # 使用方法

 img_width, img_height = 1024, 1024  # 图像尺寸

 convert_voc_to_yolo('path/to/image_0001.xml', 'path/to/image_0001.txt', img_width, img_height)




    AI写代码

 cd ultralytics


 python train.py --img 1024 --batch 16 --epochs 100 --data ../DIOR_dataset/data.yaml --weights yolov8m.pt --cache




    AI写代码

 import torch


 from ultralytics import YOLO  # 使用YOLOv8的API



 def main():

     device = torch.device('cuda' if torch.cuda.is_available() else 'cpu')

     data_yaml = '../DIOR_dataset/data.yaml'



     # 加载预训练模型

     model = YOLO('yolov8m.pt').to(device)  # 使用YOLOv8m作为基础模型



     # 设置训练参数

     epochs = 100

     batch_size = 16

     img_size = 1024



     # 开始训练

     model.train(data=data_yaml, epochs=epochs, batch=batch_size, imgsz=img_size, device=device)



     # 保存模型

     model.save('trained_model.pt')

     print('Training complete.')



 if __name__ == '__main__':

     main()




    AI写代码

    python detect.py --weights runs/train/exp/weights/best.pt --img 1024 --conf 0.4 --source ../DIOR_dataset/valid/images/

    AI写代码

    python detect.py --weights best.pt --img 1024 --conf 0.4 --source ../DIOR_dataset/valid/images/

    AI写代码
