常规钻井钻进分析

 %% time frame and time increament


 tau=2*pi/n/omiga0;

 t=-80*tau:h:100;

 %% matrix construction

 y1=zeros(size(t));y2=zeros(size(t));y3=zeros(size(t));y4=zeros(size(t));

 tao=zeros(size(t));

 %% initial value

 m=tau/h;

 for i=1:80*m+1

     y1(i)=v0;y2(i)=v0*t(i);y3(i)=omiga0;y4(i)=omiga0*t(i);

     tao(i)=m;

 end

 %% main program

 for j=80*m+1:length(t)-1

     %% equation 1

     A=[];

     kk=1:80*m;

     N=[A abs(y4(j)-y4(j-kk)-2*pi/n)];

     index=find(N==min(N));

     tao(j)=kk(:,index);

     d=n*(y2(j)-y2(j-tao(j)));

     Wbc=KFc*d*H(d)*H(y3(j));

     Wbf=KFf0*H(d)*H(y1(j));

     Wb=Wbc+Wbf;

     Fd=F0*cos(200*pi*t(j));

     y1(j+1)=y1(j)+h*(W0+Fd-Wb-Ca*(y1(j)-v0)-Ka*(y2(j)-v0*t(j)))/m1;

     %% equation 2

     y2(j+1)=y2(j)+h*y1(j);

     %% equation 3

     Tbc=KTc*d*H(d)*H(y3(j));

     Tbf=KTf0*sign(y3(j))*H(d)*H(y1(j));

     Tb=Tbc+Tbf;

     y3(j+1)=y3(j)+h*(-Tb-Ct*(y3(j)-omiga0)-Kt*(y4(j)-omiga0*t(j)))/I1;

     %% equation 4

     y4(j+1)=y4(j)+h*y3(j);

 end
