【python数字信号处理】——循环卷积（也叫圆圈卷积）

 # 循环卷积


 def cc(x1,x2):



 	# 计算两个列表的对应元素乘积之和

 	def sum_(x1,x2):

 		sumV = 0

 		for i in range(len(x1)):

 			sumV += x1[i]*x2[i]

 		return sumV



 	N = len(x1) # 共4步

 	x0 = [0 for _ in range(N)]

 	X = []

 	for i in range(N):

 		sumV = sum_(x1,x2)

 		x0[i] = sumV

 		X.append(x0[:])

 		x1 = [x1[-1]] + x1[:-1]

 	return X



 if __name__ == '__main__':

 	x = [1,1,1,1]

 	y = [4,3,2,1]

 	print(cc(x,y))





 def synthesis_matrix(N):


 	ts = np.arange(N) / N

 	freqs = np.arange(N)

 	args = np.outer(ts, freqs)

 	M = np.exp(1j * PI2 * args)

 	return M





 def dft(ys):

 	N = len(ys)

 	M = synthesis_matrix(N)

 	amps = M.conj().transpose().dot(ys)

 	return amps





 def idft(amps):

 	N = len(amps)

 	M = synthesis_matrix(N)

 	ys = M.dot(amps) / N

 	return ys
