毕设 车位识别车位检测车道线检测 - python opencv

    import os
    import numpy as np
    import cv2
    import pickle
    import argparse
    import matplotlib.pyplot as plt
    from matplotlib.patches import Polygon
    from matplotlib.widgets import PolygonSelector
    from matplotlib.collections import PatchCollection
    from shapely.geometry import box
    from shapely.geometry import Polygon as shapely_poly

    points = []
    prev_points = []
    patches = []
    total_points = []
    breaker = False

    class SelectFromCollection(object):
     def __init__(self, ax):
     self.canvas = ax.figure.canvas
     self.poly = PolygonSelector(ax, self.onselect)
     self.ind = []

     def onselect(self, verts):
     global points
     points = verts
     self.canvas.draw_idle()

     def disconnect(self):
     self.poly.disconnect_events()
     self.canvas.draw_idle()

    def break_loop(event):
     global breaker
     global globSelect
     global savePath
     if event.key == 'b':
     globSelect.disconnect()
     if os.path.exists(savePath):
     os.remove(savePath)

     print("data saved in "+ savePath + " file")
     with open(savePath, 'wb') as f:
     pickle.dump(total_points, f, protocol=pickle.HIGHEST_PROTOCOL)
     exit()

    def onkeypress(event):
     global points, prev_points, total_points
     if event.key == 'n':
     pts = np.array(points, dtype=np.int32)
     if points != prev_points and len(set(points)) == 4:
     print("Points : "+str(pts))
     patches.append(Polygon(pts))
     total_points.append(pts)
     prev_points = points

    if __name__ == '__main__':
     parser = argparse.ArgumentParser()
     parser.add_argument('video_path', help="Path of video file")
     parser.add_argument('--out_file', help="Name of the output file", default="regions.p")
     args = parser.parse_args()

     global globSelect
     global savePath
     savePath = args.out_file if args.out_file.endswith(".p") else args.out_file+".p"

     print("\n> Select a region in the figure by enclosing them within a quadrilateral.")
     print("> Press the 'f' key to go full screen.")
     print("> Press the 'esc' key to discard current quadrilateral.")
     print("> Try holding the 'shift' key to move all of the vertices.")
     print("> Try holding the 'ctrl' key to move a single vertex.")
     print("> After marking a quadrilateral press 'n' to save current quadrilateral and then press 'q' to start marking a new quadrilateral")
     print("> When you are done press 'b' to Exit the program\n")

     video_capture = cv2.VideoCapture(args.video_path)
     cnt=0
     rgb_image = None
     while video_capture.isOpened():
     success, frame = video_capture.read()
     if not success:
     break
     if cnt == 5:
     rgb_image = frame[:, :, ::-1]
     cnt += 1
     video_capture.release()

     while True:
     fig, ax = plt.subplots()
     image = rgb_image
     ax.imshow(image)

     p = PatchCollection(patches, alpha=0.7)
     p.set_array(10*np.ones(len(patches)))
     ax.add_collection(p)

     globSelect = SelectFromCollection(ax)
     bbox = plt.connect('key_press_event', onkeypress)
     break_event = plt.connect('key_press_event', break_loop)
     plt.show()
     globSelect.disconnect()
