基于K-Means聚类算法的主颜色提取

 import matplotlib.pyplot as plt


 from mpl_toolkits.mplot3d import Axes3D

 import matplotlib.colors as color





 import numpy as np

 from collections import Counter

 import pandas as pd

 import math





 from sklearn.cluster import KMeans

 from PIL import Image

 import webcolors

 import json





 import argparse

    parser = argparse.ArgumentParser()


    parser.add_argument("--clusters", help="No. of clusters")
    parser.add_argument("--imagepath", help="Path to input image")


    args = parser.parse_args()


    IMG_PATH = args.imagepath if args.imagepath else "images/poster.jpg"
    CLUSTERS = args.clusters if args.clusters else 5


    WIDTH = 128
    HEIGHT = 128





 with open('colors.json') as clr:

     color_dict = json.load(clr)

 def TrainKMeans(img):


     new_width, new_height = calculate_new_size(img)

     image = img.resize((new_width, new_height), Image.ANTIALIAS)

     img_array = np.array(image)

     img_vector = img_array.reshape((img_array.shape[0] * img_array.shape[1], 3))

     '''

     ----------

     Training K-Means Clustering Algorithm

     ----------

     '''

     kmeans = KMeans(n_clusters = CLUSTERS, random_state=0)

     labels = kmeans.fit_predict(img_vector)



     hex_colors = [rgb_to_hex(center) for center in kmeans.cluster_centers_]

     color_name = {}

     for c in kmeans.cluster_centers_:

     h, name = findColorName(c)

     color_name[h] = name



     img_cor = [[*x] for x in img_vector]

     '''

     img_cor is a nested list of all the coordinates (pixel -- RGB value) present in the


     '''

     cluster_map = pd.DataFrame()

     cluster_map['position'] = img_cor

     cluster_map['cluster'] = kmeans.labels_

     cluster_map['x'] = [x[0] for x in cluster_map['position']]

     cluster_map['y'] = [x[1] for x in cluster_map['position']]

     cluster_map['z'] = [x[2] for x in cluster_map['position']]

     cluster_map['color'] = [hex_colors[x] for x in cluster_map['cluster']]

     cluster_map['color_name'] = [color_name[x] for x in cluster_map['color']]

     print(cluster_map)

     return cluster_map, kmeans

 def calculate_new_size(image):


     '''

     We are resizing the image (one of the dimensions) to 128 px and then, scaling the

     other dimension with same height by width ratio.

     '''

     if image.width >= image.height:

     wperc = (WIDTH / float(image.width))

     hsize = int((float(image.height) * float(wperc)))

     new_width, new_height = WIDTH, hsize

     else:

     hperc = (HEIGHT / float(image.height))

     wsize = int((float(image.width) * float(hperc)))

     new_width, new_height = wsize, HEIGHT

     return new_width, new_height

 def rgb_to_hex(rgb):


     '''

     Converting our rgb value to hex code.

     '''

     hex = color.to_hex([int(rgb[0])/255, int(rgb[1])/255, int(rgb[2])/255])

     print(hex)



     return hex

 def findColorName(rgb):


     '''

     Finding color name :: returning hex code and nearest/actual color name

     '''

     aname, cname = get_colour_name((int(rgb[0]), int(rgb[1]), int(rgb[2])))

     hex = color.to_hex([int(rgb[0])/255, int(rgb[1])/255, int(rgb[2])/255])

     if aname is None:

     name = cname

     else:

     name = aname

     return hex, name





 def closest_colour(requested_colour):

     '''

     We are basically calculating euclidean distance between our set of RGB values

     with all the RGB values that are present in our JSON. After that, we are looking

     at the combination RGB (from JSON) that is at least distance from input

     RGB values, hence finding the closest color name.

     '''

     min_colors = {}

     for key, name in color_dict['color_names'].items():

     r_c, g_c, b_c = webcolors.hex_to_rgb("#"+key)

     rd = (r_c - requested_colour[0]) *

     gd = (g_c - requested_colour[1]) *

     bd = (b_c - requested_colour[2]) *

     min_colors[math.sqrt(rd + gd + bd)] = name

     #print(min(min_colours.keys()))

     return min_colors[min(min_colors.keys())]





 def get_colour_name(requested_colour):

     '''

     In this function, we are converting our RGB set to color name using a third

     party module "webcolors".



     RGB set -> Hex Code -> Color Name



     By default, it looks in CSS3 colors list (which is the best). If it cannot find

     hex code in CSS3 colors list, it raises a ValueError which we are handling

     using our own function in which we are finding the closest color to the input

     RGB set.

     '''

     try:

     closest_name = actual_name = webcolors.rgb_to_name(requested_colour)

     except ValueError:

     closest_name = closest_colour(requested_colour)

     actual_name = None

     return actual_name, closest_name

 def plotColorClusters(img):


     cluster_map, kmeans = TrainKMeans(img)

     fig = plt.figure()

     ax = Axes3D(fig)



     # grouping the data by color hex code and color name to find the total count of

     # pixels (data points) in a particular cluster

     mydf = cluster_map.groupby(['color', 'color_name']).agg({'position':'count'}).reset_index().rename(columns={"position":"count"})

     mydf['Percentage'] = round((mydf['count']/mydf['count'].sum())*100, 1)

     print(mydf)



     # Plotting a scatter plot for all the clusters and their respective colors

     ax.scatter(cluster_map['x'], cluster_map['y'], cluster_map['z'], color = cluster_map['color'])

     plt.show()



     '''

     Subplots with image and a pie chart representing the share of each color identified

     in the entire photograph/image.

     '''

     plt.figure(figsize=(14, 8))

     plt.subplot(221)

     plt.imshow(img)

     plt.axis('off')



     plt.subplot(222)

     plt.pie(mydf['count'], labels=mydf['color_name'], colors=mydf['color'], autopct='%1.1f%%', startangle=90)

     plt.axis('equal')

     plt.show()





 def main():

     img = Image.open(IMG_PATH)

     plotColorClusters(img)
