使用YOLOv8来训练一个钢材表面缺陷检测数据集，并使用OpenCV和Tkinter构建一个GUI应用程序来进行检测 ——钢材缺陷检测识别+数据集+代码

 steel_defect_dataset/


 ├── train/

 │   ├── images/

 │   └── labels/

 ├── valid/

 │   ├── images/

 │   └── labels/

 └── data.yaml  # 数据配置文件




    AI写代码

 train: ./train/images/  # 训练集图像路径


 val: ./valid/images/  # 验证集图像路径

 test: ./test/images/  # 测试集图像路径（如果有）



 # Classes

 nc: 6  # 类别数量

 names: ['crazing', 'inclusion', 'patches', 'pitted_surface', 'rolled-in_scale', 'scratches']  # 类别名称列表




    AI写代码

 pip install opencv-python-headless  # 如果不需要显示窗口，可以使用headless版本


 pip install opencv-python            # 如果需要显示窗口

 pip install ultralytics

 pip install tk




    AI写代码

 import tkinter as tk


 from tkinter import filedialog

 import cv2

 import numpy as np

 from ultralytics import YOLO



 # 加载模型

 model = YOLO("path/to/best.pt")  # 替换为实际的模型路径



 def detect_image(image_path):

     results = model.predict(source=image_path, conf=0.5)

     result = results[0]

     boxes = result.boxes.xyxy.cpu().numpy().astype(int)

     labels = result.names

     for box in boxes:

     cv2.rectangle(image, (box[0], box[1]), (box[2], box[3]), (0, 255, 0), 2)

     cv2.putText(image, labels[int(result.boxes.cls[box])], (box[0], box[1] - 10), cv2.FONT_HERSHEY_SIMPLEX, 0.9, (0, 255, 0), 2)

     cv2.imshow("Detected Image", image)

     cv2.waitKey(0)

     cv2.destroyAllWindows()



 def detect_video(video_path):

     cap = cv2.VideoCapture(video_path)

     while True:

     ret, frame = cap.read()

     if not ret:

         break

     results = model.predict(source=frame, conf=0.5)

     result = results[0]

     boxes = result.boxes.xyxy.cpu().numpy().astype(int)

     labels = result.names

     for box in boxes:

         cv2.rectangle(frame, (box[0], box[1]), (box[2], box[3]), (0, 255, 0), 2)

         cv2.putText(frame, labels[int(result.boxes.cls[box])], (box[0], box[1] - 10), cv2.FONT_HERSHEY_SIMPLEX, 0.9, (0, 255, 0), 2)

     cv2.imshow("Detected Video", frame)

     if cv2.waitKey(1) & 0xFF == ord('q'):

         break

     cap.release()

     cv2.destroyAllWindows()



 def detect_camera():

     cap = cv2.VideoCapture(0)

     while True:

     ret, frame = cap.read()

     if not ret:

         break

     results = model.predict(source=frame, conf=0.5)

     result = results[0]

     boxes = result.boxes.xyxy.cpu().numpy().astype(int)

     labels = result.names

     for box in boxes:

         cv2.rectangle(frame, (box[0], box[1]), (box[2], box[3]), (0, 255, 0), 2)

         cv2.putText(frame, labels[int(result.boxes.cls[box])], (box[0], box[1] - 10), cv2.FONT_HERSHEY_SIMPLEX, 0.9, (0, 255, 0), 2)

     cv2.imshow("Camera Detection", frame)

     if cv2.waitKey(1) & 0xFF == ord('q'):

         break

     cap.release()

     cv2.destroyAllWindows()



 def select_image():

     file_path = filedialog.askopenfilename()

     if file_path:

     image = cv2.imread(file_path)

     detect_image(image)



 def select_video():

     file_path = filedialog.askopenfilename()

     if file_path:

     detect_video(file_path)



 # 创建主窗口

 root = tk.Tk()

 root.title("钢材表面缺陷检测")



 # 创建按钮

 btn_image = tk.Button(root, text="选择图片", command=select_image)

 btn_video = tk.Button(root, text="选择视频", command=select_video)

 btn_camera = tk.Button(root, text="启动摄像头", command=detect_camera)



 # 布局

 btn_image.pack(pady=10)

 btn_video.pack(pady=10)

 btn_camera.pack(pady=10)



 root.mainloop()




    AI写代码
